Yamaha XS1100 Fours 1978 – 1981 Clymer Owners Service and Repair Manual

click here to learn more
Softcover – 278 pages – Yamaha XS1100 Fours 1978 – 1981 Clymer Owners Service Repair Manual Covers the following Models: XS1100E (1978-1981) XS1100F (1978-1981) XS1100SF (1978-1981) XS1100G (1978-1981) XS1100H (1978-1981) XS1100SG (1978-1981) XS1100SH (1978-1981)Contents: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Service hints / Torque specifications / Safety first / Mechanic #39;s tips / Parts replacement / Expendable supplies / Tools / Serial numbers TROUBLESHOOTINGOperating requirements / Troubleshooting instruments / Emergency troubleshooting / Starter / Charging system / Engine / Engine noises / Engine lubrication / Fuel system / Clutch / Transmission / Electrical problems / Excessive vibration / Front suspension and steering / Brake problems / Specifications PERIODIC MAINTENANCE LUBRICATION AND TUNE-UPRoutine checks / Service intervals / Front forks and rear shocks / Battery / Periodic lubrication / Tune-up / Storage / Specifications ENGINEEngine principles / Servicing engine in frame / Engine / Cylinder head / Valves and valve components / Cylinder / Pistons and connecting rods / Piston rings / Ignition advance mechanisms / Alternator / Oil pump / Oil pressure relief valve / Middle gear case / Secondary shaft and starter motor clutch assembly / Crankcase / Crankshaft / Kickstarter / Break-in / Specifications CLUTCH AND TRANSMISSIONClutch / Clutch cable / Shift mechanism / Transmission / Gearshift drum and forks / Specifications FUEL AND EXHAUST SYSTEMSAir cleaner / Carburetors / Fuel tank / Exhaust system / Specifications ELECTRICAL SYSTEMWiring diagrams / Charging system / Alternator / Voltage regulator/rectifier / Ignition system (fully transistorized) / Ignition coil / Ignition ballast resistor / Ignition advance mechanism / Ignition emergency shut-off switch / Spark plugs / Starting system / Lighting system / Tachometer / Fuel gauge (except special models) / Low fuel warning light (special model) / Instrument cluster / Horn / Fuses / Wiring diagrams / Specifications FRONT SUSPENSION AND STEERINGFront wheel / Front hub / Wheel balancing / Tyre changing / Tyre repairs / Handlebar / Steering head / Front fork / Specifications REAR SUSPENSION AND FINAL DRIVERear wheels / Rear hub / Wheel balancing / Final drive / Rear swing arm / Rear shocks / Specifications BRAKESFront disc brakes / Front master cylinder / Front brake pad / Fron click
