Yamaha FZR600 1989 – 1993 Clymer Owners Service and Repair Manual
Softcover – 384 pages – Yamaha FZR600 1989 – 1993 Clymer Owners Service Repair Manual Covers the Yamaha FZR600 1989-1993 sportbikesContents: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Notes cautions and warnings / Safety first / Service hints / Torque specifications / Fasteners / Lubricants / Expendable supplies / Parts replacement / Emission control and battery labels / Basic hand tools / Precision measuring tools / Special tools / Mechanic #39;s tips / Riding safety / Specifications TROUBLESHOOTINGOperating requirements / Troubleshooting instruments / Troubleshooting / Engine performance / Engine noises / Engine lubrication / Clutch / Transmission / Electrical problems / Excessive vibration / Carburetor troubleshooting / Front suspension and steering / Brake problems / Specifications PERIODIC LUBRICATION MAINTENANCE AND TUNE-UPRoutine checks / Pre-checks / Maintenance intervals / Tyres / Battery / Periodic lubrication / Engine oil and filter change / Front fork oil change / Swing arm bearing lubrication / Relay arm and connecting arm lubrication / Speedometer cable lubrication / Drive chain lubrication / Periodic maintenance / Drive chain adjustment / Drive chain slider replacement / Clutch adjustment / EXUP System Adjustment (California models) / Throttle cable adjustment / Fuel valve filter service / Air filter service / Steering play adjustment / Coolant change / Front suspension check / Rear shock absorber adjustment / Tune-up / Valve clearance adjustment / Compression test / Spark plugs / Ignition timing / Idle speed inspection and adjustment / Carburetor synchronization Specifications / Torque ENGINEServicing engine in frame / Engine principles / Engine / Cylinder head cover and camshafts / Camshaft chain tensioner / Cylinder head / Valve and valve components / Cylinder block / Pistons piston pins and piston rings / Oil pump and strainer / Oil level switch / Crankcase / Crankshaft / Connecting rods / Starter clutch and gears / Break-in / Specifications CLUTCHClutch / Clutch release mechanism / Clutch cable / Specifications TRANSMISSIONDrive sprocket cover / Engine sprocket / External shift mechanism / Transmission gears / Internal shift mechanism / Specifications FUEL EMISSION CONTROL AND EXHAUST SYSTEMSCarburetor / Fuel level / Fuel tank / Fuel shutoff valve / Fuel filter / Fuel pump / Evaporative emission control (California mo click the link
