Volkswagen Transporter T4 Diesel Only 1996-1999 Workshop Manual Get other VW repair manuals here Volkswagen Transporter T4 Diesel Only 1996-1999 Workshop Manual Covers all T4 diesel vehicles from January 1996 up to and including 1999Engines covered: #9679; Diesel 1.9L 4 Cylinder 1X #9679; Diesel 2.4L 5 Cylinder AAB #9679; Diesel 2.5L TDI 5 Cylinder ACV fitted with a catalytic converter exhaust gas recirculation turbo charger and a charge air intercoolerModels Covered: #9679; Van 800 Van 1 000 Van 1 200 #9679; Caravelle CL and GL #9679; Bus (long and short wheelbase)Index: #9679; Engine #9679; Clutch #9679; Transmission and Final Drive #9679; Drive Shafts #9679; Steering #9679; Front Suspension #9679; Rear Suspension #9679; Wheels and Tyres #9679; Brakes #9679; Electrical System #9679; BodyworkWiring Diagram – 1.9 Litre Diesel Engine: #9679; Engine Type ABL Alternator Battery Starter Motor #9679; Ignition / Starter Switch #9679; Control Unit for Glow Time and Exhaust Gas Return System (EGR) #9679; Glow Plugs and Coolant Run-On #9679; Dash Panel Insert Oil Pressure and Coolant Monitor Fuel Guage Glow Time Warning LampWiring Diagram – 2.4 Litre Natural Aspirating Diesel Motor – Engine Code AAB: #9679; Alternator Starter Motor Continued Coolant Circulation #9679; Pre-Glow System Fuel Guage Sender Engine Temperature Sender Coolant Shortage Warning Sender #9679; Dash Panel Insert Oil Pressure Switch Speedometer Sender Fuel Shut-Off Valve Heater Element #9679; Dash Panel Insert Fuel Guage Coolant Temperature Gauge Glow Plug Period Warning Lamp Speedometer Distance Recorder #9679; Transporter T4 from January 1996 – Base Equipment #9679; Ignition / Starter Switch Immobiliser #9679; Fresh Air Blower Air Blower Switch Glove Compartment Lamp #9679; Dash Panel Insert Oil Pressure and Coolant Warning / Guage Fuel Guage #9679; Dash Panel Insert Rev Counter Distance Recorder Turn Signal Warning Lamps #9679; Dash Panel Insert Clock Handbrake Warning Switch #9679; Self Diagnosis Junction Box Radio Connection #9679; Interior Lights Door Contacts #9679; Headlamps (Long Front End) Side Lamps #9679; Headlamps Range Control Hazard Warning Lights #9679; Turn Signal Switch Headlamp Dipped Beam / Flasher Switch Parking Light Switch #9679; Flasher Lamps (Turn Signals) Brake Lights Tail (Rear) Lights #9679; Light Switch Rear Fog Lamp #9679; Cigare click the link
