Toyota 5L-E engine factory workshop and repair manual

click here to learn more
Toyota 5L-E engine factory workshop and repair manual on PDF can be viewed using PDF reader like adobe or foxit or nitro . It is compressed as a zip file which you can extract with 7zip File size 12 MbCovers 5L BELT INSTALL 5L COMPONANTS 5L CRANK ANGLE SENSOR 5L DRIVE BELT COMPONANTS 5L ECD SYSTEM DIAGRAM 5L ENGINE COMPONANTS 5L ENGINE REMOVAL 5L ENGINE UNIT COMPONANTS 5L FRONT OIL SEAL INSTALL 5L FRONT OIL SEAL REMOVAL 5L FRONT SEAL COMPONANTS 5L HEAD COMPONANTS 5L HEAD INSTALL 5L HEAD REMOVAL 5L INJECTIOR NOZZLE COMPONANTS 5L INJECTOR PUMP COMPONANTS 5L REAR OIL SEAL COMPONANTS 5L SERVICE SPECS 5L TORQUE SPECS 5L VENTURI COMPONANTS 5L-E ENGINE SUP. RM817E CAM INSTALL CAM REMOVAL ECD SYSTEM ENGINE TIMING BELT COMPONANTS ENGINE UNIT DIASSEMBLY ENGINE UNIT REASSEMBLY PRESSURE SENSOR RAR OIL SEAL INSTALL REAR OIL SEAL REMOVAL TIMING BELT INSTALL TIMING BELT REMOVAL VALVE CLEARANCE ADJUSTMENTSearchable document with bookmarks. About the 5L-E engine The 5L-E is a 3.0 L (2 986 cc) EFI version of the 5L engine. It is the latest member of the L family. It has a bore of 99.5 mm and stroke of 96.0 mm with a compression ratio of 22.2:1. Output (as fitted to the Hilux is 97 PS (71 kW) at 4 000 rpm with 192 N m (142 ft lb) of torque at 2 400 rpm.Power output varies according to fitment. The engine number is found on the top face of the block at the front of the engine.Applications: Toyota Hilux Toyota Land Cruiser Prado (J90-series) Toyota Hiace (fifth generation H200-series)Toyota 5L-E engine factory workshop and repair manual more tips
