Toyota 1HD-FT engine factory workshop and repair manual

click here to learn more
Toyota 1HD-FT engine factory workshop and repair manualon PDF can be viewed using PDF reader like adobe or foxit or nitro File size 37 Mb in 259 pages INTRODUCTION PREPARATION SERVICE SPECIFICATION DIAGNOSTIC SYSTEM ENGINE MECHANICAL INTAKE AIR/SHUTTER SYSTEM TURBOCHARGING SYSTEM EMISSION CONTROL ELECTRONIC CONTROL DIESEL FUEL INTAKE TEMPERATURE FUEL SYSTEM INJECTION SYSTEM COOLING SYSTEM LUBRICATION SYSTEM STARTING SYSTEM ALTERNATOR SYSTEM CHARGING SYSTEM TORQUE SPECIFICATIONSST AND SSM SYSTEMThe 1HD-FT is a 4.2 L (4164 cc) straight-6 24 valve SOHC turbocharged diesel engine of direct injection design. Bore is 94 mm and stroke is 100 mm with a compression ratio of 18.6:1. Known as the quot;multivalve quot; it has 4 valves per cylinder (2 inlet 2 exhaust) central vertically mounted injector and no glow plugs but rather an intake glow screen heater (like the later electronic 1HD-FTE below). The 4 valves per cylinder are actuated by the SOHC by using bridges so each rocker actuates a pair of valves. Output is 168 hp (125 kW) ECE at 3600 rpm with 380 N m (280 ft-lb) of torque ECE at 2500 rpm.Toyota 1HD-FT engine factory workshop and repair online click the link
