Suzuki LT230 and LT250 1985 – 1990 Clymer Owners Service and Repair Manual

click here to learn more
Softcover. 264 pages – – Suzuki LT230 LT250 1985 – 1990 Clymer Owners Service Repair Manual Covers the following Models: LT230S Chain Drive (1985-1988) LT-F230G Shaft Drive (1985-1987) LT230G Shaft Drive (1985-1986) LT250S Chain Drive (1989-1990)Table of Contents QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Service hints / Torque specifications / Safety first / Service hints / Special tips / Expendable supplies / Parts replacement / Serial numbers / Basic hand tools / Tune-up and troubleshooting tools / Mechanic #39;s tips / Off road rules / Riding safely TROUBLESHOOTINGOperating requirements / Emergency troubleshooting / Engine starting / Engine performance / Engine noises / Excessive vibration / Front suspension and steering / Brake problems LUBRICATION MAINTENANCE AND TUNE-UPPre-ride checklist / Service intervals schedule / Periodic lubrication / Engine oil and filter change / Control cable lubrication / Non-scheduled lubrication / Periodic maintenance / Non-scheduled maintenance / Reverse cable adjustment / Tune-up / Valve clearance / Compression test check / Spark plug / Air filter / Specifications ENGINEEngine principles / Engine cooling / Serving engine in frame / Engine removal and installation / Cylinder head cover and rocker arm assembly / Cylinder head and camshaft / Valves and valve seats / Cylinder / Piston piston pin and piston rings / Oil pump / Cam chain tensioner / Kickstarter (chain-driven models) / Recoil starter (shaft-driven models) / Starter gears (shaft-driven models) / Secondary bevel gear and drive gear set (shaft-driven models) / Crankcase and crankshaft / Break-in procedure / Specifications CLUTCH AND TRANSMISSIONClutch operation / Centrifugal clutch / Manual clutch / Manual clutch inspection / Clutch lifting mechanism (shaft-driven models) / Clutch release mechanism (chain-driven models) / Clutch cable (chain-driven models) / External shift mechanism / Drive sprocket (chain-driven) / Transmission and internal shift mechanism / Dual-range subtransmission (shaft-driven LT-F230) / Specifications FUEL AND EXHAUST SYSTEMSCarburetor operation / Carburetor service / Throttle cable / Choke cable (shaft-driven models) / Fuel shutoff valve / Fuel tank / Fuel pump (shaft-driven models) / Exhaust system / Specifications ELECTRICAL SYSTEMCharging system (models so equipped) / Voltage regulator (shaft-driven models) / Alter come here
