Suzuki DR650SE 1996 – 2013 Clymer Owners Service and Repair Manual

click here to learn more
Softcover – 304 pages – Suzuki DR650SE 1996 – 2013 Clymer Owners Service Repair Manual covers 1996-2013 SUZUKI DR650SE.Table of Contents: General InformationManual organization / Warnings cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Tools / Measuring tools / Electrical system fundamentals / Service methods / Storage / Specifications Specs TroubleshootingStarting the engine / Engine spark test / Engine performance / Electrical testing / Starting system / Engine noise / Motorcycle noise / Engine lubrication / Engine leakdown test / Clutch / Gearshift linkage and transmission / Brakes / Disc brake troubleshooting / Specifications Specs Lubrication Maintenance and Tune-upPeriodic inspection / Tune-up / Air filter / Engine oil and filter / Idle speed adjustment / Spark plugs / Compression test / Ignition timing inspection / Brake system / Clutch / Fuel hose inspection / Emission control system / Throttle cables / Choke cable / Tyres and wheels / Valve clearance / Lights and horn inspection / Sidestand switch and ignition cut-off system / Steering head bearing inspection / Front suspension inspection / Front fork oil change / Rear suspension inspection / Drive chain / Speedometer cable / Muffler / Fasteners / Specifications Specs Engine Top EndExhaust system / Cylinder head cover / Rocker arm assemblies / Camshaft / Cylinder head / Valves / Cam chain tensioner / Cylinder / Piston piston pin and piston rings / Specifications Specs Engine Lower EndLeft crankcase cover / Starter idler gear and torque limiter / Flywheel alternator rotor and starter clutch / Right crankcase cover / Camshaft chain / Oil pump / Primary drive gear / Crankshaft ring nut / Crankcase / Countershaft seal / Crankcase bearings / Balancer assembly / Oil screen / Oil jet / Crankshaft / Break-in / Specifications Specs Clutch and External Shift MechanismClutch / Clutch release mechanism / External shift mechanism / Clutch cable replacement / Specifications Specs Transmission and Internal Shift MechanismMainshaft / Countershaft / Transmission inspection / Shift drum and forks / Specifications Specs Fuel and Emission Control SystemCarburetor / Pilot screw / Carburetor float height / Throttle cables / Choke cable / Air box / Fuel tank / Fuel valve / Crankcase breather system / Evaporative emissions control system / Specifications Specs Electrical SystemContinuity testin more details…..
