Piaggio and Vespa Scooters 1991 – 2009 Haynes Owners Service and Repair ManualWith Carburettor Engines

click here to learn more
Softcover – 368 pages – Piaggio Vespa Scooters 1991 – 2009 Haynes Owners Service Repair Manual covers the following models: Piaggio Sfera 50 80 125 – 1991-1998 Piaggio Typhoon 50 80 125 – 1993- 2009 Piaggio Zip 2T SP RS 4T 100 125 – 1993 -2009 Piaggio Fly 50 2T 50 4T 100 125 – 2005-2009 Piaggio Skipper 125 Skipper ST 125 – 1993-2004 Piaggio Hexagon 125 Super Hexagon 125 – 1994-2003 Piaggio Liberty 50 2T 50 4T 125 – 1997-2009 Piaggio NRG MC2 50 MC3 DT 50 MC3 DD 50 Power DT 50 Power DD 50 – 1997-2009 Piaggio B125 Beverly 125 – 2001-2008 Piaggio X9 125 X8 125 2001-2008 Vespa ET2 2T 50 ET2 4T 50 ET4 125 – 1996-2004 Vespa LX2 50 LX4 50 LXV50 LX125 LXV125 – 2005-2009 Vespa S50 S125 – 2007-2009 Vespa GT125 GTS125 GTV125 GT200 – 2003-2009Note: this manual covers carburetor models only. The 2009 LX125 S125 and GTS125 Super i.e. were fitted with fuel injected engines in certain markets.Contents: Living With Your PIAGGIO/VESPA Scooter- Introduction:- The Piaggio Story- Identification Numbers- Buying Spare Parts- Safety First! Pre-Ride Checks:- Engine Oil Level Check (four-stroke models)- Fuel and Two-Stroke Oil Checks- Coolant Level Chcek (liquid-cooled models)- Brake Fluid Level Check – Disc Brake Models- Tyre Checks; Suspension and Steering Checks- Legal and Safety Checks Maintenance- Routine Maintenance and Servicing:- Model Specifications and Service Schedules- Routine Maintenance and Servicing Procedures. Repairs And Overhaul- Engine Transmission and Associated Systems:- Air-Cooled Two-Stroke Engines: Sfera 50/80 all Typhoons Liberty 50 Zip 50 NRG MC3 DT NRG Power DT ET2 Skipper Fly 50 LX2p 50- Liquid-Cooled Two-Stroke Engines: NRG MC2 NRG MC3 DD NRG Power DD Zip SP Hexagon- Four-Stroke Engines: Sfera 125 Liberty 125 ET4- Four-Stroke Engines: ET4 50 Liberty 50 4T Zip 50 4T Fly 50 4T LX4 50- Four-Stroke LEADER Air-Cooled Engines: Zip 125 Skipper ST Liberty 125 ET4 Fly 125 LX4 125- Four-Stroke LEADER Liquid-Cooled Engines: Super Hexagon B125 X9 125 X8 125 GT125 GT200- Transmission- Cooling System (Liquid-Cooled Engines- Fuel and Exhaust Systems- Ignition System Chassis Components:- Steering and Suspension- Frame and Bodywork- Brakes Wheels and Tyres Electrical System- Wiring Diagrams more details…..
