Mitsubishi Pajero NL-NW repair manual 1997-2014 Haynes

click here to learn more
Mitsubishi Pajero Series NL to NT Petrol Diesel 1997 – 2014 Australian Models Manual covering the Mitsubishi Pajero Series NL NM NP NS NT NW four wheel drive also known as the Montero and Shogun in other markets.Note: This manual DOES NOT cover the smaller Pajero Io (also known as Pinin) model. While it does not specifically cover the Triton (also known as the L200) the Australian market Triton was sold with the 6G72 and 4M40 engines which are covered in this manual.Note: Wiring diagrams are not included for the NS and NT series.Petrol Engines Covered: 3.0 litre V6 SOHC 12v (6G72) 3.5 litre V6 SOHC DOHC 24v (6G74) 3.8 litre V6 SOHC 8v (6G75)Diesel Engines Covered: 2.8 litre 4 cylinder (4M40) 2.8 litre 4 cylinder turbo (4M40T) 3.2 litre 4 cylinder turbo (4M41)Transmissions Covered: 4-speed manual 5-speed manual 4-speed and 5 speed automaticContents: Introductory Pages About this Manual; Introduction to the Mitsubishi Pajero; Vehicle Identification Numbers; Recall Information; Buying Parts; Maintenance Techniques Tools and Working Facilities; Jacking and Towing; Booster Battery (jump) starting; Automotive Chemicals and Lubricants; Conversion Factors; Fraction/Decimal/Millimeter Equivalents; Troubleshooting Tune Up and Routine Maintenance V6 Petrol Engines 2.8 litre Diesel Engine 3.2 litre Diesel Engine General Engine Overhaul Procedures Cooling Heating and Air Conditioning Systems Fuel and Exhaust Systems Engine Electrical Systems Emissions and Engine Control Systems Manual Transmission Automatic Transmission Transfer Case Clutch and Drivetrain Brakes Suspension and Steering Systems Body Chassis Electrical System Wiring Diagrams (NS and NT series are not covered)NOTE: Only maintenance adjustment minor repair procedures plus removal and installation are described for the Automatic Transmission. more tips
