Get other Land Rover repair manuals hereLand Rover 90 110 Defender Diesel 1983 – 2007 Haynes Owners Service Repair Manual Covers: Land Rover 90 110 and Defender Diesel models from 1983 to 1995 including Pick-up Hard and Soft-top County and Station Wagon.PLEASE NOTE: DOES NOT cover 2.4 Litre TDi Diesel Engine Petrol Engine Models or Land Rover Special Vehicle Options and ConversionsEngines Covered: 2.25 litre (2286 cc) OHV 4 Cylinder Diesel 10J 1983 – 1984 2.25 litre (2495 cc) OHV 4 Cylinder Diesel code 12J 1984 – 1986 2.5 litre (2495 cc) Turbocharged OHV 4 Cylinder Diesel 19J 1986 – 9/1990 2.5 litre (2495 cc) Turbocharged Intercooled OHV 4 Cylinder Diesel 200TDi 9/1990 – 1994 2.5 litre (2495 cc) Turbocharged Intercooled OHV 4 Cylinder Diesel 300TDi 1994 on 2.5 litre (2498 cc) Turbocharged Intercooled SOHC 5 Cylinder Diesel TD5 11/1998 onTransmissions described (NOTE: No overhaul procedures are described for gearboxes or transfer boxes): LT77 5-speed manual (10J 12J or 19J Engine) LT77S 5-spees manual (200 TDi Engine) R380 5-speed manual (300 TDi or TD5 Engine) LT230R transfer box (10J or 12J Engine) LT230T transfer box (19J 200 TDi or 300 TDi Engine) LT230TE transfer box (TD5 Engine)Contents: Living with Your Land Rover Defender Roadside Repairs Weekly Checks Lubricants Fluids Tyre Pressures Routine Maintenance Service Non TD5 Engine Engine In-Car Repair Procedures TD5 Engine In-Car Repair Procedures Engine Removal General Overhaul Procedures Cooling Heating Air Conditioning Systems Fuel Exhaust Emission Control Systems – Non TD5 Engines Fuel Exhaust Emission Control Systems – TD5 Engines Engine Electrical Systems Clutch Manual Gearbox Transfer Gearbox Propeller Shaft Front Rear Axles Braking System Suspension Steering Bodywork Fittings Body Electrical Systems Wiring DiagramsNOTE: Only maintenance adjustment minor repair procedures plus removal and installation are described for the Transmissions.control ignition brakes suspension and steering electrical systems and wiring diagrams.. click
