Kawasaki Bayou KLF220 and KLF250 1988 – 2010 ATVClymer Owners Service and Repair Manual

click here to learn more
Softcover – 412 pages – Kawasaki Bayou KLF220 KLF250 1988 – 2010 ATV Clymer Owners Service Repair Manual covers the following models: KLF220 Bayou (1988-2002) KLF250 Bayou (2003-2010)Contents: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Notes cautions and warnings / Safety first / Service hints / Washing the vehicle / Torqu specifications / Fasteners / Lubricants / Threadlocking compound / Expendable supplies / Serial numbers / Warning labels / Basic hand tools / Precision measuring tools / Special tools / Mechanic #39;s tips / Ball bearing replacement / Oil seals / Riding safely / Specifications TROUBLESHOOTINGOperating requirements / Troubleshooting instruments / Starting hte engine / Engine starting difficulties / Engine will not start / Poor idle or off idle performance / Poor medium and high speed performance / Engine starting system / Charging system / Ignition system / Fuel system / Engine overheating / Engine noises / Engine leak down test / Clutch / Transmission / Drive train noise / Handling / Frame noise / Brakes LUBRICATION MAINTENANCE AND TUNE-UPPre-ride checklist / Service intervals schedule / Periodic lubrication / Engine oil and filter change / Final drive oil change / Control cable lubrication / Non-scheduled lubrication / Periodic maintenance / Non-scheduled maintenance / Reverse cable adjustment / Tune-up / Valve clearance / Compression test check / Spark plug / Air filter / Ignition timing / Pilot screw adjustment / Idle Speed Adjustment / Storage / Specifications ENGINE TOP ENDEngine principles / Cylinder head / Compression release lever / Camshaft and rocker arms / Cam chain / Chain guides / Valves and valve components / Cylinder / Piston and piston rings / Specifications ENGINE LOWER ENDServicing engine in frame / Engine removal / Engine installation / Balancer gears and oil pump drive gear / Oil screen / Oil pump / Oil pipes / Left-hand side cover / Stator coil and pickup coil / Flywheel and starter clutch / Crankcase and crankshaft / Recoil starter / Engine break-in / Specifications CLUTCH PRIMARY DRIVE AND EXTERNAL SHIFT MECHANISMClutch cover / Clutch release mechanism / Clutch / Gear backlash check / One-way clutch check / External shift mechanism / Specifications TRANSMISSION AND INTERNAL SHIFT MECHANISMTransmission/reverse system identification / Transmission troubleshooting / Transmission/reverse overhaul / information
