Honda XL/XR 250 and 500 1978 – 1984 Haynes Owners Service and Repair Manual

click here to learn more
Softcover – 192 pages – Honda XL/XR 250 500 1978 – 1984 Haynes Owners Service Repair Manual Covers the following Models: Honda XL80S U.S. only 1979-1985 Honda XR80 U.K. 1979-1980 U.S. 1978-1984 Honda XR80R U.S. only 1984-1987 Honda XL100S U.K. 1978-1983 U.S. 1979-1985 Honda XR100 U.S. only 1981-1984 Honda XR100R U.S. only 1984-1987 Honda XL125S U.K. 1978-1973 U.S. 1978-1982 1984 Honda XL125R U.K. only 1982-1987 Honda XL185S U.K. 1987-1982 U.S. 1978-1983 Honda XR185 U.S. only 1979 Honda XL200R U.S. only 1982-1984 Honda XR200 U.K. 1980 U.S. 1979-1984 Honda XR200R U.K. 1982-1983 U.S. 1981-1983 1986 1987Note: This manual does not include the RFVC modelsContents: Maintenance Engine Clutch And Transmission Fuel System And Lubrication Ignition System Frame And Forks Wheels Brakes And Tyres Electrical System Including Wiring Diagrams related info
