Honda VTX1300 Series 2003 – 2009 Clymer Owners Service and Repair Manual

click here to learn more
Softcover – 424 pages – Honda VTX1300 Series 2003 – 2009 Clymer Owners Service Repair Manual covers the following manuals: Honda VTX1300S 2003-2007 Honda VTX1300C 2004-2009 Honda VTX1300R 2005-2009 Honda VTX1300T 2008-2009Contents: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Warnings cautions and notes / Safety / Serial numbers and information labels / Shop supplies / Tools / Measuring tools /Electrical system fundamentals / Service methods / Storage / Specifications TROUBLESHOOTINGStarting the engine / Engine will not start / Poor engine performance / Fuel system / Engine / Engine lubrication / Cylinder leakdown test / Clutch / Gearshift linkage / Transmission / Electrical testing / Final drive / Front suspension and steering / Brake system MAINTENANCE LUBRICATION and TUNE-UPTune-up / Air filter / Engine compression test / Spark plugs / Ignition timing / Valve clearance / Idle speed adjustment / Fuel system hose inspection / Fuel filter / Throttle cable / Clutch cable and clutch lever / Engine oil and filter / Engine oil pressure check / Cooling system / Front fork oil change / Specifications ENGINERemoval installation / Cylinder head covers and rocker arms / Camshafts / Cam chain tensioner and cam chain / Cylinder head / Valves and valve components / Cylinder / Piston and piston rings / Cylinder stud / Crankcase / Crankcase seal and bearing / Crankshaft / Connecting rods / Balancer shafts / Oil pump / Output gear / Specifications CLUTCH AND EXTERNAL SHIFT MECHANISMRight crankcase cover / Clutch release assembly / Primary drive and driven gears and oil pump chain and sprockets / External shift mechanism / Specifications TRANSMISSION AND INTERNAL SHIFT MECHANISMSpecifications FUEL AND EMISSION CONTROL SYSTEMSFuel system differences / Fuel tank / Fuel valve / Air filter housing / Carburetor / Intake manifold / Pilot screw adjustment idle drop procedure / High altitude adjustment / Throttle cable replacement / Choke cable replacement / Fuel pump and fuel filter / Crankcase breather system / Pulse secondary air supply system / Evaporative emission control system / (California models) / Specifications ELECTRICAL SYSTEMElectrical component replacement / Electrical connectors / Battery / Battery box / Charging system / Stator coil ignition pulse generator and left crankcase cover / Flywheel starter clutch and starter drive gears / Ignition syst find out more…..
