Honda GL1500 Gold Wing 1993 – 2000 Clymer Owners Service and Repair Manual

click here to learn more
Softcover – 792 pages – Honda GL1500 Gold Wing 1993 – 2000 Clymer Owners Service Repair Manual Covers the following Models: GL1500SE Gold Wing Special Edition (1993-2000) GL1500A Gold Wing Aspencade (1993-2000) GL1500I Gold Wing Interstate (1993-2000)Contents: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Notes cautions and warnings / Safety first / Service hints / Serial numbers / Parts replacement / Torque specifications / Fasteners / Lubricants / RTV Gasket sealant / Threadlock / Gasket remover / Expendable supplies / Basic hand tools / Test equipment / Precision measuring tools / Cleaning solvent / Other special tools / Mechanic #39;s tips / Ball bearing replacement / Oil seals / Riding safely / Specifications TROUBLESHOOTINGOperating requirements / Emergency troubleshooting / Engine starting procedures / Engine starting troubleshooting / Engine performance / Engine noises / Hydraulic valve adjuster system / Engine lubrication / Fuel system / Clutch / Transmission / Final drive / Excessive vibration / Front suspension and steering / Brake problems/ Electrical troubleshooting LUBRICATION MAINTENANCE AND TUNE-UPRoutine checks / Pre-checks / Service intervals / Tyres and wheels / Crankcase breather hose / Evaporation emission control / Periodic lubrication / Periodic maintenance / Rear suspension air shock adjustment / Tune-up / Specifications ENGINE TOP END AND EXHAUST SYSTEMEngine principles / Engine rotation / Servicing engine in the frame / Camshaft timing belts and pulleys / Camshaft and rocker assemblies / Hydraulic tappet / Cylinder heads / Valves and valve components / Engine front cover / Exhaust system / Specifications ENGINE BOTTOM ENDSpecial tools / Parts requiring engine removal / Service precautions / Engine removal / Engine mounts / Engine installation / Rear engine cover / Reverse shift system / Starter drive gear (GL1500I) / Alternator clutch assembly / Primary drive and driven gears / Final drive gear / Shift drum lock system (GL1500 models with reverse) / Scavenging oil pump / Cylinder block / Pistons and connecting rods / Crankshaft and connecting rods / Break-in procedure / Specifications CLUTCHClutch hydraulic system / Master slave cylinder / Bleeding / Specifications TRANSMISSIONExternal shift mechanism / Internal shift mechanism / Output shaft / Specifications FUEL AND EMISSION CONTROL SYSTEMSAir filter / Carburetor click to go
