Honda CB500 and CBF500Twin 1993 – 2008 Haynes Owners Service and Repair Manual

click here to learn more
Hardcover – 240 pages – Honda CB500 CBF500Twin 1993 – 2008 Haynes Owners Service Repair Manual Covers the following Models: CB500 499cc 1993 – 2002 CB500S 499cc 1998 – 2002 CBF500 499cc 2003 – 2007 CBF500A 499cc 2003 – 2008Contents: Identification Numbers Buying Spare Parts Bike Specs Routine Maintenance and Servicing Specifications Maintenance Schedule Component Locations Maintenance Procedures Engine Clutch and Transmission Fuel and Exhaust Systems Ignition System Frame and Suspension Brakes Wheels and Final Drive Fairing and Bodywork Electrical System Wiring Diagrams Tools and Workshop Tips Storage Troubleshooting further data
