Honda 100cc – 350cc OHC Singles 1969-1982 Clymer Owners Service and Repair Manual

click here to learn more
Softcover – 352 pages – Honda Singles 100cc – 350cc OHC 1969-1982 Clymer Owners Service Repair Manual Covers the following Models: Honda CB100 Honda CB125S Honda CL100 Honda CT125 Honda SL100 Honda SL125 Honda TL125 Honda TL250 Honda XL100 Honda XL125 Honda XL175 Honda XL250 Honda XL350Contents: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Service hints / Torque specifications / Safety first / Special tips / Parts replacement / Expendable supplies / Serial numbers / Tune-up and troubleshooting tools TROUBLESHOOTINGOperating requirements / Troubleshooting instruments / Emergency troubleshooting / Engine starting / Engine performance / Excessive vibration / Front suspension and steering / Brake problems LUBRICATION MAINTENANCE AND TUNE-UPRoutine checks / Service intervals / Tyres and wheels / Crankcase breather hose / Battery / Periodic lubrication / Engine oil change / Oil filter screen cleaning / Front fork oil change / Periodic maintenance / Drive chain adjustment/ Front brake lever adjustment / Rear brake pedal adjustment / Clutch adjustment / Air filter service / Fuel shutoff valve and filter service / Engine tune-up / Camshaft chain tensioner adjustment / Valve clearance adjustment / Spark plugs / Contact breaker point adjustment / Static ignition timing adjustment / Dynamic ignition timing adjustment / Idle speed adjustment / Specifications 100 AND 125 CC ENGINESEngine principles / Engine cooling / Servicing engine in frame / Engine removal/installation / Camshaft / Cylinder head / Cylinder head cover and camshaft / Camshaft chain / Valves and valve components / Cylinder / Piston piston pin and piston rings / Oil pump / Crankcase and crankshaft / Camshaft chain and tensioner / Kickstarter / Break-in procedure / Specifications 175 250 AND 350 CC ENGINESEngine principles / Engine cooling / Servicing in frame / Engine removal/installation / Cylinder head cover and camshaft / Camshaft chain / Cylinder head / Valves and valve components / Cylinder / Piston piston pin and piston rings / Oil pump / Crankcase and crankshaft / Camshaft chain and tensioner / Kickstarter / Break-in procedure / Specifications CLUTCH AND TRANSMISSIONClutch operation / Clutch / Clutch inspection / Clutch cable / External shift mechanism / Drive sprocket / Transmission and internal shift mechanism / 5-speed transmission and internal shift mechanism / Specifications click on
