Holden Astra TS and Zafira TT 1998-2005 Haynes Owners Service and Repair ManualOther Holden Astra Car Repair Manuals click here NEW paperback Holden Astra (TS) Zafira (TT) 1998-2005 Haynes Owners Service Repair Manual covers models: Holden Astra Hatchback Sedan and Wagon and Zafira MPV models with Petrol engines including special / limited editions. #9679; DOES NOT cover bi-fuel models 1.6 L Twinport or 2.0 L turbo engines coupe or convertible. #9679; DOES NOT cover AH series introduced Sept 2004.Petrol Engines Covered: #9679; 1.4 litre (1389cc) DOHC – X14XE Z14XE #9679; 1.6 litre (1598cc) SOHC – X16SZR (single point injection) #9679; 1.6 litre (1598cc) SOHC – Z16SE (multi-point injection) #9679; 1.6 litre (1598cc) DOHC – X16XEL Z16XE #9679; 1.8 litre (1796cc) DOHC – X18XE1 Z18XE Z18XEL #9679; 2.0 litre (1998cc) DOHC – X20XEV #9679; 2.2 litre (2198cc) DOHC – Z22SETransmissions described: #9679; F13 5-speed manual (1.4-litre and SOHC 1.6-litre engines) #9679; F17 5-speed manual (1.4-litre DOHC 1.6-litre and 1.8-litre engines) #9679; F18 5-speed manual (2.0-litre engines) #9679; F23 5-speed manual (2.2-litre engines) #9679; AF13 4-speed automatic (1.4- and 1.6-litre engines) #9679; AF17 4-speed automatic (1.8-litre engines) #9679; AF20 4-speed automatic (2.0-litre engines) #9679; AF22 4-speed automatic (2.2-litre engines)Contents: #9679; Living with Your Holden Astra/Zafira #9679; Roadside Repairs #9679; Weekly Checks #9679; Lubricants Fluids #9679; Tyre Pressures #9679; Routine Maintenance Service #9679; 1.4 1.6 1.8 2.0 litre DOHC Engine In-Car Repair Procedures #9679; 2.2 litre DOHC Engine In-Car Repair Procedures #9679; Engine Removal Overhaul Procedures #9679; Cooling Heating Air Conditioning Systems #9679; Fuel Exhaust Systems #9679; Emission Control Systems #9679; Starting Charging Systems #9679; Ignition System #9679; Clutch #9679; Manual Transmission #9679; Automatic Transmission #9679; Driveshafts #9679; Braking System #9679; Suspension Steering #9679; Bodywork Fittings #9679; Body Electrical Systems #9679; Wiring Diagrams – Holden Astra #9679; Wiring Diagrams – Holden ZafiraNOTE: Only maintenance adjustment minor repair procedures plus removal and installation are described for the Transmissions.Inside this manual you will find: Routine Maintenance tune-up procedures engine repair cooling and heating air-condit extra
