Harley Davidson Shovelheads 1966 – 1984 Clymer Owners Service and Repair Manual

click here to learn more
Softcover – 426 pages – Harley Davidson Shovelheads 1966 – 1984 Clymer Owners Service Repair Manual Covers the following Models: Harley-Davidson FL 1973-1984 Harley-Davidson FXE 1974-1984 Harley-Davidson FLH 1973-1984 Harley-Davidson FXEF 1980-1984 Harley-Davidson FXB 1980-1984 Harley-Davidson Super Glide (FL) 1971 Harley-Davidson FLHS 1980-1983 Harley-Davidson FXS 1978-1984 Harley-Davidson FXSB 1980-1984 Harley-Davidson FX 1973-1979 Harley-Davidson FXWG 1980-1984 Harley-Davidson Electra Glide (FL) 1966-1972Contents: QUICK REFERENCE DATA GENERAL INFORMATION TROUBLESHOOTINGEmergency troubleshooting / Engine starting / Engine noises / Engine lubrication / Clutch / Electrical problems / Breaker point ignition troubleshooting / Breakerless ignition troubleshooting / Excessive vibration / Carburetor troubleshooting / Specifications PERIODIC LUBRICATION MAINTENANCE AND TUNE-UPMaintenance schedule intervals / Periodic lubrication / Periodic maintenance / Engine oil and filter change / Suspension adjustment / Breaker point ignition service / Breakerless ignition service / Carburetor adjustments / Specifications ENGINERemoval installation / Rocker arm cover / Cylinder head / Pushrods / Valves and components / Cylinder / Pistons and rings / Oil pump / Gearcase cover and timing gears / Crankcase / Specifications CLUTCH PRIMARY DRIVE TRANSMISSION AND KICKSTARTERPrimary chain / Primary belt / Compensating sprocket / Primary chain/belt case / Transmission / Hand shifter cover (1966-early 1978) / Foot shifter (1966-early 1979) / Shifter cover (late 1979-1984) / Shift forks / Kickstarter and starter clutch / Side cover (electric start) / Electric starter drive / Shifter adjustment / Specifications FUEL AND EXHAUST SYSTEMSAir cleaner / Carburetors / Throttle cable / Fuel tank / Fuel supply valve / Exhaust system / Specifications ELECTRICAL SYSTEMCharging system / Voltage regulator (1966-1969) / Circuit breaker / Ignition system / Ignition coil / Starter / Starter solenoid / Lighting system / Switches / Horn / Fuses and circuit breakers / Specifications FRONT SUSPENSION AND STEERINGFront wheel / Front hub / Wheel balance / Tyre changing / Handlebar and throttle control / Steering head / Front fork / Specifications REAR SUSPENSIONRear wheel / Rear hub / Driven sprocket assembly / Drive chain / Drive belt / Wheel balancing / Tyre changing / Rear swing arm / Shock absorbers / details
