Harley Davidson FLH FLT FXR Evolution 1984 – 1998 Clymer Owners Service Repair Manual Covers the following Models: FLHR Road King (1995-1998) FLHR-I Road King (1996-1997) FLHRC-I Road King (1998) FLHS Electra Glide Sport (1988-1993) FLHT Electra Glide (1995-1998) FLHTC Electra Glide Classic Anniversary (1984-1998) FLHTC-I Electra Glide Classic (1996-1998) FLHTC-U Electra Glide Classic-Ultra Anniversary (1989-1997) FLHTC-UI Electra Glide Classic-Ultra Anniversary (1996-1998) FLTC Tour Glide (1984-1991) FLTC-U Tour Glide-Ultra Classic (1989-1995) FLTC-UI Tour Glide-Ultra Classic (1996) FLTR Road Glide (1998) FLTR-I Road Glide (1998) FXEF Fat Bob (1985) FXLR Low Rider Custom Anniversary (1987-1994) FXR Super Glide (1986-1994) FXR2 FXR3 Super Glide ( Limited edition models available only in 1999) FXRD Super Glide Grand Touring (1986) FXRS Low Rider Convertible (1984-1992) FXRS-Con Low Rider-Convertible (1991-1993) FXRS-SP Low Rider-Sport Edition (1988-1993) FXRT Sport Glide (1984-1992) FXSB Low Rider (1985) FXWG Wide Glide (1985-1986)Contents: QUICK REFERENCE DATA GENERAL INFORMATION Manual organization / Warnings cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Basic tools / Special tools / Precision measuring tools / Electrical system fundamentals / Basic service methods / Storage / Specifications TROUBLESHOOTING Engine principles / Operating requirements / Starting the engine / Engine performance / Starting system / Charging system / Ignition system (carbureted models) / Ignition system (fuel-injected models) / Engine management system diagnostic codes / Cruise control system diagnostic codes / Fuel system (carbureted models) / Fuel system (electronic fuel injection) / Engine noises / Engine lubrication / Clutch / Transmission / Lighting system / Excessive vibration / Front suspension and steering / Brake problems / Specifications LUBRICATION MAINTENANCE AND TUNE-UP Routine safety checks / Pre-ride inspection / Maintenance schedule intervals / Periodic lubrication / Oil and filter change / Oil tank flushing / Transmission oil change / Primary chaincase oil change / Drive chain lubrication / Control cable lubrication / Periodic maintenance / Primary chain adjustment / Drive belt deflection adjustment / Tune-up / Ignition service / Carburetor adjustments / Specifications ENGINE Removal installation / Rocker arms and covers / Cylinder h extra
